| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 14.87 IN |
| CATALOG NUM | P184 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 10.8 A |
| FRAME | 56Z |
| FRAME LENGTH | 6.55 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1 HP |
| INSULATION CLASS | B |
| KVA CODE | D |
| LEAD TIME | 18 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | P184 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Ring |
| NOMINAL EFFICIENCY | 70.5 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.63 IN X 6 IN |
| SHAFT DIAMETER IN IN | 0.63 IN |
| SHAFT EXTENSION | 6 IN |
| SKU | MTG-P184 |
| SPEED | 1075 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856038029 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 33 LB |
