| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| CATALOG NUM | P180 |
| CE | No |
| CONNECTION DRAWING NO | 154A2455 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 6.3-6.4/3.2 A |
| FRAME | 56Z |
| FRAME LENGTH | 8.99 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.5 IN |
| HORSE POWER | 1 HP |
| INSULATION CLASS | B |
| KVA CODE | B |
| LEAD TIME | 21 |
| LENGTH | 17.69 IN |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | P180 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 59 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any Drive End |
| OVERLOAD | Automatic |
| PART ID | 5KCP49WN9813S |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 825(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.63 IN X 6 IN |
| SHAFT DIAMETER IN IN | 0.63 IN |
| SHAFT EXTENSION | 6 IN |
| SKU | MTG-P180 |
| SPEED | 825 |
| STATUS | Active |
| SUPPLIER | Marathon Electric Mfg Co |
| THRU BOLTS EXTENSION | 1 |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856038012 |
| VOLTAGE | 200-230/460 V |
| WEIGHT STATIC | 45 LB |
| WIDTH | 7.69 IN |
