| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 15.31 IN |
| CATALOG NUM | K1497 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 9.2-9.6,4.8 A |
| FRAME | 56HZ |
| FRAME LENGTH | 10.71 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 3 HP |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 18 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | K1497 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 83.6 |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.15 |
| SHAFT | 0.88 IN X 2.25 IN |
| SHAFT DIAMETER IN IN | 0.88 IN |
| SHAFT EXTENSION | 2.25 IN |
| SKU | MTG-K1497 |
| SPEED | 1725 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856040954 |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 44 LB |
