| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 10.38 IN |
| CATALOG NUMBER | K1487 |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED NON VENTILATED |
| FL AMPS | 2.1-2.0/1.0 A |
| FRAME | 56 |
| FREQUENCY | 60 HZ |
| INSULATION CLASS | B |
| KVA CODE | P |
| LEAD TIME | 18 |
| MANUFACTURE MODEL NUMBER | K1487 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MOTOR TYPE | 3Ph |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 69.9 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OUTPUT | 1/3 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/3,1200,200-230/460,56,TEAO,3PH |
| PRODUCT SKU | MTG-K1487 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1140/950(1) |
| SERVICE FACTOR | 1.5 |
| SHAFT | 0.63 IN X 1.88 IN |
| SHAFT DIAMETER (IN IN.) | 0.63 IN |
| SHAFT EXTENSION | 1.88 IN |
| SPEED | 1140/950 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 200-230/460 V |
