| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 11.7 IN |
| CATALOG NUM | H222 |
| CATALOG NUM STATIC | H222 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 4.2/2.9 A |
| FRAME | 56CZ |
| FRAME LENGTH | 7.15 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56Cz |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/6 HP |
| HORSE POWER STATIC | 6-Jan |
| INSULATION CLASS | B |
| KVA CODE | N |
| LEAD TIME | 17 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | H222 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | C-Face Footless |
| NOMINAL EFFICIENCY | 47 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1140/850(1) |
| RPM STATIC | 1200 |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.63 IN X 2.25 IN |
| SHAFT DIAMETER IN IN | 0.63 IN |
| SHAFT EXTENSION | 2.25 IN |
| SKU | MTG-H222 |
| SPEED | 1140/850 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856041357 |
| VOLTAGE | 115 V |
| VOLTAGE STATIC | 115 |
| WEIGHT STATIC | 25 lB |
