| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | LEESON |
| C DIMENSION | 13.96 IN |
| CATALOG NUM | C1909 |
| CE | N |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Y |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | Totally Enclosed Air Over |
| FRAME | 56 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.5 |
| HORSE POWER | 1-1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 15.14 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | #REF! |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | CAPACITOR START / CAPACITOR RUN |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| POWER RATING IN KW | 1.1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1800 |
| SERVICE FACTOR | 1.3 |
| SHAFT DIAMETER IN IN | 0.630 IN |
| SHAFT EXTENSION | 1.88 |
| SKU | MTG-C1909 |
| SPEED | 1725 |
| SUPPLIER | Marathon Electric Mfg Co |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856028143 |
| VOLTAGE | 115/208-230 V |
| WEIGHT STATIC | 49 LB |
| WIDTH | 10.19 |
