| BEARING | Ball |
| BLOWER TYPE | Furnace |
| BRAND | Marathon Electric Mfg Co |
| CATALOG NUMBER | 4739 |
| CONNECTION DRAWING NO | 52A105379AA |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 4 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.5 IN |
| INSULATION CLASS | B |
| KVA CODE | N |
| LEAD TIME | 18 |
| LENGTH | 13.69 IN |
| MANUFACTURE MODEL NUMBER | 4739 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Ring |
| NOMINAL EFFICIENCY | 64.5 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2,1800,230,48Y,ODP,SPLIT |
| PRODUCT SKU | MTG-4739 |
| ROTATION | Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.500 IN X 1.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 1.5 IN |
| SPEED | 1725 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Automatic |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230 V |
| WIDTH | 7.13 IN |
