| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Fasco Industries Inc |
| C DIMENSION | 8.64 IN |
| CATALOG NUM | 3252 |
| CE | No |
| CONNECTION DRAWING NO | NP24X327691 |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 0.9 A |
| FRAME | 48 |
| FRAME LENGTH | 3.07 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/6 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | 3252 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Ring |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 4 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 4 IN |
| SKU | MTG-3252 |
| SPEED | 1075 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 815585022398 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 8 LB |
