| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Genteq |
| C DIMENSION | 8.53 IN |
| CATALOG NUM | 3143 |
| CE | No |
| CONNECTION DRAWING NO | NP24X327583 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 8.6 A |
| FRAME | 48 |
| FRAME LENGTH | 4.57 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.94 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 14.12 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | 3143 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 5 |
| ORIENTATION | Any |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 1075(5) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 3.25 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 3.25 IN |
| SHAFT TYPE | Flat |
| SKU | MTG-3143 |
| SPEED | 1075 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 815585021636 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 15 LB |
| WIDTH | 10.88 IN |
