| BEARING | Sleeve |
| BRAND | Fasco Industries Inc |
| C DIMENSION | 10.95 IN |
| CATALOG NUMBER | 3084 |
| CONNECTION DRAWING NO | NP24X327691 |
| DUTY | Continuous Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 1.5 A |
| FRAME | 48 |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.02 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 14.06 IN |
| MANUFACTURE MODEL NUMBER | 3084 |
| MANUFACTURER | Fasco Industries Inc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Down |
| OUTPUT | 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/4,1200,208-230,48,TEAO,PSC |
| PRODUCT SKU | MTG-3084 |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 6 IN |
| SHAFT DIAMETER (IN IN.) | 0.5 IN |
| SHAFT EXTENSION | 6 IN |
| SHAFT TYPE | Double Flat |
| SPEED | 1075 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 6.04 IN |
