| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Genteq |
| C DIMENSION | 7.38 IN |
| CATALOG NUM | 3051 |
| CE | No |
| CONNECTION DRAWING NO | NP24X327052 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.3 A |
| FRAME | 48 |
| FRAME LENGTH | 3.32 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.02 IN |
| HORSE POWER | 1/6 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13.24 IN |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | 3051 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Round |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| PRODUCT GROUP | 3050 |
| ROTATION | Clockwise |
| RPM | 1550(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 2.5 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 2.5 IN |
| SHAFT TYPE | Double Flat |
| SKU | MTG-3051 |
| SPEED | 1550 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 815585023432 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 10 LB |
| WIDTH | 6.04 IN |
