| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Genteq |
| C DIMENSION | 6.09 IN |
| CATALOG NUM | 2743 |
| CE | No |
| CONNECTION DRAWING NO | NP24X32708 |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 0.83 A |
| FRAME | 42 |
| FRAME LENGTH | 3.16 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/8 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| MANUFACTURER | Fasco Industries Inc |
| MFG MODEL NUM | 2743 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Round |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 1650(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 2 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 2 IN |
| SHAFT TYPE | Flat |
| SKU | MTG-2743 |
| SPEED | 1650 |
| SUPPLIER | Fasco Industries Inc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| VOLTAGE | 200-230 V |
| WEIGHT STATIC | 7 LB |
