| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | LEESON |
| C DIMENSION | 13.32 IN |
| CATALOG NUM | 111962 |
| CATALOG NUM STATIC | 111962 |
| CE | No |
| CONNECTION DRAWING NO | 5046.01 |
| COUNTRY OF ORIGIN | USA |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | DRIP PROOF |
| FL AMPS | 5 & 2.6 A |
| FRAME | 56H |
| FRAME LENGTH | 7.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | N/A |
| FREQUENCY | 60 HZ |
| HEIGHT | 10.88 IN |
| HORSE POWER | 1-1/2 & 67/100 HP |
| HORSE POWER STATIC | 1/1/2002 |
| INSULATION CLASS | B |
| KVA CODE | K |
| LEAD TIME | 21 |
| LENGTH | 14.44 IN |
| MANUFACTURER | Leeson Electric Corp |
| MFG MODEL NUM | 111962 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| PART ID | 111962 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725 & 1140(1) |
| RPM STATIC | 1725 |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.88 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.88 IN |
| SHAFT TYPE | NEMA 56 |
| SKU | ML-111962 |
| SPEED | 1725 & 1140 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Leeson Electric Corp |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 691720010464 |
| VOLTAGE | 230 & 208-230 V |
| VOLTAGE STATIC | 208/230 |
| WEIGHT STATIC | 43 LB |
| WIDTH | 10.44 IN |
