| BEARING | Ball |
| BRAND | LEESON |
| C DIMENSION | 12.32 IN |
| CATALOG NUMBER | 111953 |
| CONNECTION DRAWING NO | 5203.01 |
| DUTY | Continuous |
| ENCLOSURE | DRIP PROOF |
| FL AMPS | 7.8 & 4.6 A |
| FRAME | 56H |
| FREQUENCY | 60 HZ |
| HEIGHT | 10.88 IN |
| INSULATION CLASS | B |
| KVA CODE | N |
| LEAD TIME | 21 |
| LENGTH | 14.44 IN |
| MANUFACTURE MODEL NUMBER | 111953 |
| MANUFACTURER | Leeson Electric Corp |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/2 & 11/50 HP |
| PRODUCT NAME | 1/2 HP 2 SP 1 PH 56 FR 115/230 |
| PRODUCT SKU | ML-111953 |
| ROTATION | Selective Counterclockwise |
| RPM | 1725 & 1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.88 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.88 IN |
| SHAFT TYPE | NEMA 56 |
| SPEED | 1725 & 1140 |
| SUPPLIER | Leeson Electric Corp |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 7.94 IN |
