| BEARING | Ball |
| BRAND | LEESON |
| C DIMENSION | 11.98 IN |
| CATALOG NUMBER | 110088 |
| DUTY | Continuous |
| ENCLOSURE | Totally Enclosed Fan Cooled |
| FRAME | 56 |
| FREQUENCY | 60 HZ |
| HEIGHT | 10.88 IN |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 14.44 IN |
| MANUFACTURE MODEL NUMBER | M6C17FB10L |
| MANUFACTURER | Leeson Electric Corp |
| MOTOR TYPE | CAPACITOR START |
| MOUNTING | Rigid Base |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1 HP |
| PRODUCT NAME | 1HP,1725,56FR,HIGH TORQUE |
| PRODUCT SKU | ML-110088 |
| ROTATION | Counterclockwise |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.88 |
| SPEED | 1725 |
| SUPPLIER | Leeson Electric Corp. |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/230 V |
| WIDTH | 10.44 IN |
