| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 15.10 IN |
| CATALOG NUM | X603 |
| CATALOG NUM STATIC | X603 |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 12.0/5.8-6.0 A |
| FRAME | 56 |
| FRAME LENGTH | 7.06 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56 |
| FREQUENCY | 60 HZ |
| HORSE POWER | 3/4 HP |
| HORSE POWER STATIC | 4-Mar |
| INSULATION CLASS | B |
| KVA CODE | K |
| LEAD TIME | 21 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X603 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Cap |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 66 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Fixed Counterclockwise |
| RPM | 1725(1) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.625 IN X 5.66 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 5.66 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-X603 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856042040 |
| VOLTAGE | 208-230/115 V |
| VOLTAGE STATIC | 115/208-230 |
| WEIGHT STATIC | 29 LB |
