| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 11.19 IN |
| CATALOG NUM | X417 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.4-1.85 A |
| FRAME | 48Z |
| FRAME LENGTH | 3.75 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/4 HP |
| INSULATION CLASS | B |
| KVA CODE | D |
| LEAD TIME | 30 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X417 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Ring |
| NOMINAL EFFICIENCY | 59.4 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 6.06 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 6.06 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-X417 |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856038746 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 13 LB |
