| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 9 IN |
| CATALOG NUMBER | X301 |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 2.2 A |
| FRAME | 48Z |
| FREQUENCY | 60 HZ |
| INSULATION CLASS | B |
| KVA CODE | C |
| LEAD TIME | 30 |
| MANUFACTURE MODEL NUMBER | X301 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 55 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/6 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/6,1800,115,48Y,TEAO,PSC, |
| PRODUCT SKU | MAR-X301 |
| ROTATION | Selective Counterclockwise |
| RPM | 1625(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 2.81 IN |
| SHAFT DIAMETER (IN IN.) | 0.5 IN |
| SHAFT EXTENSION | 2.81 IN |
| SHAFT TYPE | Single Special Extension |
| SPEED | 1625 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
