| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 6.46 IN |
| CATALOG NUM | X269 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.1-1.2 A |
| FRAME | 48Y |
| FRAME LENGTH | 3.62 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/6 HP |
| INSULATION CLASS | B |
| KVA CODE | B |
| LEAD TIME | 40 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X269 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Through Bolt |
| NOMINAL EFFICIENCY | 67.5 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Fixed Clockwise |
| RPM | 1625(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 1.46 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 1.46 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-X269 |
| SPEED | 1625 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856049117 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 11 LB |
