| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 10.06 IN |
| CATALOG NUM | X259 |
| CATALOG NUM STATIC | X259 |
| CE | No |
| CSA | No |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.8-1.8/0.9 A |
| FRAME | 56Z |
| FRAME LENGTH | 6.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 48Y |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/3 HP |
| HORSE POWER STATIC | 3-Jan |
| INSULATION CLASS | B |
| KVA CODE | M |
| LEAD TIME | 17 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X259 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 72 |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1140(1) |
| RPM STATIC | 1200 |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.56 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.56 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-X259 |
| SPEED | 1140 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| VOLTAGE | 208-230/460 V |
| VOLTAGE STATIC | 208-230/460 |
| WEIGHT STATIC | 29 LB |
