| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 13.49 IN |
| CATALOG NUM | X251 |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 13.5-12.4/6.2 A |
| FRAME | 56HZ |
| FRAME LENGTH | 9.56 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 5 HP |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 17 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X251 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 84 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 3450(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 2.25 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 2.25 IN |
| SHAFT TYPE | NEMA 145T |
| SKU | MAR-X251 |
| SPEED | 3450 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | No |
| UOM | Each |
| UPC NUMBER | 722856049094 |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 50 LB |
