| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 12.22 IN |
| CATALOG NUM | X209 |
| CE | No |
| CONNECTION DRAWING NO | 6906496 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.8 A |
| FRAME | 48Y |
| FRAME LENGTH | 5.25 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.94 IN |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | B |
| KVA CODE | D |
| LEAD TIME | 21 |
| LENGTH | 13.25 IN |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X209 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 57.5 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 048A8O183 |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 825(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 5.53 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 5.53 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-X209 |
| SPEED | 825 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856049087 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 17 LB |
| WIDTH | 7 IN |
