| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 20 IN |
| CATALOG NUM | X065 |
| CE | No |
| CONNECTION DRAWING NO | 6906495 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1 A |
| FRAME | 48Y |
| FRAME LENGTH | 3.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6 IN |
| HORSE POWER | 1/8 HP |
| INSULATION CLASS | B |
| KVA CODE | D |
| LEAD TIME | 21 |
| LENGTH | 22 IN |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | X065 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 51.7 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 048A11O2012 |
| PRODUCT GROUP | 3050 |
| ROTATION | Fixed Counterclockwise |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 7.81 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 7.81 IN |
| SHAFT TYPE | Special Extension Both Sides |
| SKU | MAR-X065 |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856039088 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 6.25 IN |
