| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 11.97 IN |
| CATALOG NUM | O231 |
| CATALOG NUM STATIC | O231 |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 13.0/7.4-6.5 A |
| FRAME | 56C |
| FRAME LENGTH | 8 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56C |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1-1/2 HP |
| HORSE POWER STATIC | 1.5 |
| INSULATION CLASS | B |
| KVA CODE | H |
| LEAD TIME | 17 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | O231 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Cscr |
| MOUNTING | C-Face Footless |
| NOMINAL EFFICIENCY | 78.7 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 3450(1) |
| RPM STATIC | 3600 |
| SERVICE FACTOR | 1.3 |
| SHAFT | 0.625 IN X 2.09 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 2.09 IN |
| SHAFT TYPE | T |
| SKU | MAR-O231 |
| SPEED | 3450 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856041715 |
| VOLTAGE | 208-230/115 V |
| VOLTAGE STATIC | 115/208-230 |
| WEIGHT STATIC | 25 LB |
