| BEARING | Sleeve |
| BRAND | Marathon Electric Mfg Co |
| CATALOG NUMBER | O201 |
| CONNECTION DRAWING NO | A-EE7195D |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 5.6 A |
| FRAME | 56C |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.69 IN |
| INSULATION CLASS | B |
| KVA CODE | T |
| LEAD TIME | 21 |
| LENGTH | 13.44 IN |
| MANUFACTURE MODEL NUMBER | O201 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFR. MODEL | O201 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Oil Burner |
| NOMINAL EFFICIENCY | 63.4 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/3 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/3,3600,115,56C,ODP,SPLIT |
| PRODUCT SKU | MAR-O201 |
| ROTATION | Fixed Clockwise |
| RPM | 3450(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.625 IN X 2 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 2 IN |
| SHAFT TYPE | NEMA 56 |
| SPEED | 3450 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 8.69 IN |
