| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 7.7 IN |
| CATALOG NUM | O100 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 2.3 A |
| FRAME | 48MZ |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/7 HP |
| INSULATION CLASS | B |
| KVA CODE | V |
| LEAD TIME | 1 |
| MFG MODEL NUM | O100 |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | NEMA Flange |
| NOMINAL EFFICIENCY | 46.5 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Clockwise |
| RPM | 3450(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 1.84 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 1.84 IN |
| SKU | MAR-O100 |
| SPEED | 3450 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UPC NUMBER | 722856041579 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 11 LB |
