| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 8.35 IN |
| CATALOG NUM | O012 |
| CATALOG NUM STATIC | O012 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 3.0/1.5 A |
| FRAME | 48N |
| FRAME LENGTH | 4.75 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 48N |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/5 HP |
| HORSE POWER STATIC | 5-Jan |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 21 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | O012 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Cap |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 61 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Clockwise |
| RPM | 3450(1) |
| RPM STATIC | 3600 |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 1.97 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 1.97 IN |
| SHAFT TYPE | NEMA 48 |
| SKU | MAR-O012 |
| SPEED | 3450 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856041555 |
| VOLTAGE | 115/230 V |
| VOLTAGE STATIC | 115/230 |
| WEIGHT STATIC | 14 LB |
