| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 8.13 IN |
| CART2QUOTE QUOTABLE | Use Default |
| CATALOG NUM | O004 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 4.3 A |
| FRAME | 48NZ |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| GIFT WRAPPING AVAILABLE | No |
| HORSE POWER | 1/4 HP |
| INSULATION CLASS | B |
| IS FEATURED | No |
| KVA CODE | S |
| LEAD TIME | 17 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | O004 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 56.5 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Clockwise |
| RPM | 3450(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 2.09 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 2.09 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-O004 |
| SPEED | 3450 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856041517 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 13 LB |
