| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 7.59 IN |
| CATALOG NUM | O002 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 3.9 A |
| FRAME | 48N |
| FRAME LENGTH | 4.25 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/4 HP |
| INSULATION CLASS | B |
| KVA CODE | M |
| LEAD TIME | 35 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | O002 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Flange |
| NOMINAL EFFICIENCY | 60.2 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Manual |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Clockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.5 IN X 1.97 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 1.97 IN |
| SHAFT TYPE | NEMA 48 |
| SKU | MAR-O002 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856041494 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 12 LB |
