| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 11.35 IN |
| CATALOG NUM | G142 |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3.4-3.6/1.8 & 3.4/1.7-1.8 A |
| FRAME | 56 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60/50 HZ |
| HORSE POWER | 1 HP, 3/4 HP |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 21 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | G142 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 77 & 74 |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725/1425(1) |
| SERVICE FACTOR | 1.15 |
| SHAFT | 0.625 IN X 1.91 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.91 IN |
| SHAFT TYPE | T |
| SKU | MAR-G142 |
| SPEED | 1725/1425 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856040749 |
| VOLTAGE | 208-230/460 V & 190/380-415 V |
| WEIGHT STATIC | 26 LB |
