| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 9.97 IN |
| CATALOG NUMBER | G106 |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 1.5-1.6/.8 & 1.6/.8 A |
| FRAME | 56Z |
| FREQUENCY | 60/50 HZ |
| INSULATION CLASS | B |
| KVA CODE | N |
| LEAD TIME | 21 |
| MANUFACTURE MODEL NUMBER | G106 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MOTOR TYPE | 3Ph |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 66 & 64 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/3 HP, 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/3,1800,208-230/460,56,ODP,3PH |
| PRODUCT SKU | MAR-G106 |
| ROTATION | Reversible |
| RPM | 1725/1425(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.625 IN X 1.97 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.97 IN |
| SHAFT TYPE | NEMA 56 |
| SPEED | 1725/1425 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230/460 V & 190/380 V |
