| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| CATALOG NUM | E261A |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 5.2-4.4/2.6-2.2 & 5.8-5.2/2.9-2.6 A |
| FRAME | 56C |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60/50 HZ |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| KVA CODE | K |
| LEAD TIME | 21 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | E261A |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 76.2 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 1725/1425(1) |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.63 IN X 1.88 IN |
| SHAFT DIAMETER IN IN | 0.63 IN |
| SHAFT EXTENSION | 1.88 IN |
| SHAFT TYPE | Standard 56 |
| SKU | MAR-E261A |
| SPEED | 1725/1425 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856055866 |
| VOLTAGE | 100-120/200-240 V |
| WEIGHT STATIC | 25 LB |
