| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 10.97 IN |
| CATALOG NUM | E253A |
| CE | Yes |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3.65/1.8 A |
| FRAME | 56 |
| FRAME LENGTH | 7 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 21 |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | E253A |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | Rigid Base |
| NOMINAL EFFICIENCY | 72.4 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.625 IN X 1.97 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.97 IN |
| SHAFT TYPE | NEMA 56 |
| SKU | MAR-E253A |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856004376 |
| VOLTAGE | 115/230 V |
| WEIGHT STATIC | 21 LB |
