| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Belt Drive |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 10.09 IN |
| CATALOG NUM | D163 |
| CE | No |
| CONNECTION DRAWING NO | A-EE7195 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3.6 A |
| FRAME | 48Z |
| FRAME LENGTH | 6.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.62 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 17 |
| LENGTH | 11.06 IN |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | D163 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 66 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 048S17D2088 |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.5 IN X 1.59 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 1.59 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-D163 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856039941 |
| VOLTAGE | 230 V |
| WEIGHT STATIC | 19 LB |
| WIDTH | 6.75 IN |
