| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 9.95 IN |
| CATALOG NUM | B313 |
| CE | No |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 5.2/2.8-2.6 A |
| FRAME | 48Y |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HORSE POWER | 1/4 HP |
| INSULATION CLASS | B |
| KVA CODE | M |
| LEAD TIME | 1 |
| MFG MODEL NUM | B313 |
| MIN QUANTITY INCREMENT | 1 |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 57.5 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.5 IN X 2.01 IN |
| SHAFT DIAMETER IN IN | 0.5 IN |
| SHAFT EXTENSION | 2.01 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-B313 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UPC NUMBER | 722856062031 |
| VOLTAGE | 208-230/115 V |
| WEIGHT STATIC | 16 LB |
