| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Belt Drive |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 12.22 IN |
| CATALOG NUM | B193 |
| CE | Yes |
| CONNECTION DRAWING NO | A-EE7335 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 8.9-8.4/4.2 A |
| FRAME | 56HZ |
| FRAME LENGTH | 7.56 |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.12 IN |
| HORSE POWER | 3 HP |
| INSULATION CLASS | B |
| KVA CODE | J |
| LEAD TIME | 21 |
| LENGTH | 16.38 IN |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | B193 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 84 |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 056T34D5357 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 3450(1) |
| SERVICE FACTOR | 1.15 |
| SHAFT | 0.625 IN X 2.28 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 2.28 IN |
| SHAFT TYPE | Single Special Extension |
| SKU | MAR-B193 |
| SPEED | 3450 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | H845 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856040671 |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 34 LB |
| WIDTH | 10.5 IN |
