| AMBIENT | 40 °C |
| BEARING | Ball |
| BLOWER TYPE | Belt Drive |
| BRAND | Marathon Electric Mfg Co |
| C DIMENSION | 10.47 IN |
| CATALOG NUM | B100 |
| CE | Yes |
| CONNECTION DRAWING NO | A-EE7196 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 7.2/3.6 A |
| FRAME | 56 |
| FRAME LENGTH | 6.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.94 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| KVA CODE | L |
| LEAD TIME | 17 |
| LENGTH | 13.25 IN |
| MANUFACTURER | Marathon Electric Mfg Co |
| MFG MODEL NUM | B100 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 66 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | 056S17D2064 |
| PRODUCT GROUP | 3050 |
| ROTATION | Selective Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.625 IN X 1.97 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.97 IN |
| SHAFT TYPE | NEMA 56 |
| SKU | MAR-B100 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | RB2054DV2 |
| SUPPLIER | Marathon Electric Mfg Co |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 722856039811 |
| VOLTAGE | 115/230 V |
| WEIGHT STATIC | 20 LB |
| WIDTH | 7 IN |
