Haysite ETS Sheets 3/4 IN, 36 IN X 36 IN - Fiberglass-Reinforced Thermoset Polyester Laminate Sheet, GPO-1 Rated

Haysite ETS Sheets 3/4 IN, 36 IN X 36 IN - Fiberglass-Reinforced Thermoset Polyester Laminate Sheet, GPO-1 Rated

SKU:ETS-3/4-36X36

UOM:Sheet

Contact Us For Pricing

COLOR	Buff
GRADE	ETS
MATERIAL	Fiberglass-Reinforced Thermoset Polyester
NEMA	GPO-1
PRODUCT NAME	Haysite ETS Sheets 3/4 IN, 36 IN X 36 IN - Fiberglass-Reinforced Thermoset Polyester Laminate Sheet, GPO-1 Rated
PRODUCT SKU	ETS-3/4-36X36
PROPERTIES	HB - Flame Resistant
RECOMMENDED STORAGE	Indoors, out of direct sunlight
SHELF LIFE	Indefinite
SIZE	36 IN X 36 IN
SUPPLIER	HAYSITE REINFORCED PLASTICS
SUPPLIER NUMBER	53630
SUPPLIER PART NUMBER	M100524-003
TEMPERATURE INDEX ELEC/MECH	130ºC / 160ºC
TENSILE STRENGTH	10,000 PSI
THICKNESS	3/4 IN
UL APPROVED	Yes
UL FILE NUMBER	E81893
UNIT OF MEASURE	Sheet
