The 180 mm deep groove ball bearing 6317 features an 85 mm bore diameter, 180 mm outer diameter, and 41 mm width, constructed with a pressed steel cage and single shield design. It offers a basic dynamic load rating of approximately 133,000 to 140,000 N and a static load rating near 96,500 N, supporting speeds up to 8,000 rpm (reference) and limiting speed around 5,000 rpm. Operating temperature ranges from -40 to 100 °C. The bearing is made from high-quality steel (GCr15/SAE52100) with precision class P6 or 0, suitable for radial loads in applications like fans and pumps. Sleeve bearings for 6024, 6220, and 6317 have an approximate outer diameter of 187 mm and length of 80 mm, designed for oversized fits. These components ensure low noise, reduced maintenance, and high durability.
