| BEARING | Ball |
| BRAND | Century |
| CATALOG NUMBER | H988L |
| CONNECTION DRAWING NO | 17564815.PCX |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 4.4/9.0-8.8 A |
| FRAME | R56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| INSULATION CLASS | F |
| LEAD TIME | 17 |
| LENGTH | 19 IN |
| MANUFACTURE MODEL NUMBER | H988L |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | 3Ph |
| MOUNTING | Cushion Ring |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 3 HP |
| PRODUCT NAME | 3,1800,208-230/460,56Y,DP,3PH |
| PRODUCT SKU | CM-H988L |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.15 |
| SHAFT | 0.875 IN X 2.31 IN |
| SHAFT DIAMETER (IN IN.) | 0.875 IN |
| SHAFT EXTENSION | 2.31 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230/460 V |
| WIDTH | 10 IN |
