| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 11.68 IN |
| CATALOG NUMBER | H984L |
| CONNECTION DRAWING NO | 18304024.PCX |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3.4-3.4/1.7 A |
| FRAME | LA56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 15.5 IN |
| MANUFACTURE MODEL NUMBER | H984L |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | 3Ph |
| MOUNTING | Cushion Ring |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1 HP |
| PRODUCT NAME | 1,1800,208-230/460,56Y,ODP,3PH |
| PRODUCT SKU | CM-H984L |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.625 IN X 1.37 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.37 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230/460 V |
| WIDTH | 10.5 IN |
