| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 11.4 IN |
| CATALOG NUMBER | H717V1 |
| CONNECTION DRAWING NO | 17050701.PCX |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3.2-3.4/1.8-2.2 A |
| FRAME | K56 |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 13 IN |
| MANUFACTURE MODEL NUMBER | H717V1 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | 3Ph |
| MOUNTING | Cushion Base |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 2 |
| OUTPUT | 1 HP |
| PRODUCT NAME | 1,1800(2),200-230,56,ODP,3PH |
| PRODUCT SKU | CM-H717V1 |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725/1140(2) |
| SERVICE FACTOR | 1.15 |
| SHAFT | 0.625 IN X 1.94 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.94 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725/1140 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 200-230 V |
| WIDTH | 10 IN |
