| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 16.52 IN |
| CATALOG NUMBER | H667V1 |
| CONNECTION DRAWING NO | DD10027-001 |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 4.6/2.3 A |
| FRAME | 56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 8 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 19 IN |
| MANUFACTURE MODEL NUMBER | H667V1 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | 3Ph |
| MOUNTING | Round |
| NOMINAL EFFICIENCY | 72 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1,1200,200-230/460,56Y,OAO,3PH |
| PRODUCT SKU | CM-H667V1 |
| ROTATION | Reversible |
| RPM | 1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 6.06 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 6.06 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1140 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230/460 V |
| WIDTH | 8 IN |
