| AMBIENT | 70 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 18.85 IN |
| CATALOG NUM | H1053AV1 |
| CE | No |
| CONNECTION DRAWING NO | DD10027-001 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 5.1-5.4/2.7 A |
| FRAME | 56HZ |
| FRAME LENGTH | 10.15 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| HORSE POWER | 1 HP |
| INSULATION CLASS | F |
| LEAD TIME | 17 |
| LENGTH | 23 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | H1053AV1 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | H1053AV1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 850(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 6 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 6 IN |
| SHAFT TYPE | Keyed |
| SKU | CM-H1053AV1 |
| SPEED | 850 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674074089 |
| VOLTAGE | 208-230/460 V |
| WEIGHT STATIC | 50 LB |
| WIDTH | 10 IN |
