| AMBIENT | 60 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 16.81 IN |
| CATALOG NUM | C770V1 |
| CE | No |
| CONNECTION DRAWING NO | 17564827.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 2.4/4.8 A |
| FRAME | M56Y |
| FRAME LENGTH | 6.75 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 8 IN |
| HORSE POWER | 1 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 19 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C770V1 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NOMINAL EFFICIENCY | 70 |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | C770V1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Clockwise |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 6 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 6 IN |
| SHAFT TYPE | Keyed |
| SKU | CM-C770V1 |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674016829 |
| VOLTAGE | 200-230/460 V |
| WEIGHT STATIC | 35 LB |
| WIDTH | 8 IN |
