| AMBIENT | 65 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 9.59 IN |
| CATALOG NUM | C723V1A |
| CE | No |
| CONNECTION DRAWING NO | D0000313-002 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 6.4/3.6-3.1 A |
| FRAME | F48Y |
| FRAME LENGTH | 5.88 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C723V1A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | C723V1A |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1075/900(1) |
| SERVICE FACTOR | 1.5 |
| SHAFT | 0.50 IN X 2.47 IN |
| SHAFT DIAMETER IN IN | 0.50 IN |
| SHAFT EXTENSION | 2.47 IN |
| SHAFT TYPE | Flat |
| SKU | CM-C723V1A |
| SPEED | 1075/900 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674016768 |
| VOLTAGE | 200-230/115 V |
| WEIGHT STATIC | 20 LB |
| WIDTH | 7 IN |
