| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 11.44 IN |
| CATALOG NUM | C536 |
| CATALOG NUM STATIC | C536 |
| CE | No |
| CONNECTION DRAWING NO | 17050311.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 6.8/4.0 A |
| FRAME | K56 |
| FRAME LENGTH | 5.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56 |
| FREQUENCY | 60 HZ |
| HEIGHT | 11 IN |
| HORSE POWER | 1/2 HP |
| HORSE POWER STATIC | 2-Jan |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 17 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C536 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 1Ph |
| MOUNTING | Cushion Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 2 |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725/1140(2) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.625 IN X 1.94 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.94 IN |
| SHAFT TYPE | Keyed |
| SKU | CM-C536 |
| SPEED | 1725/1140 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674057211 |
| VOLTAGE | 115 V |
| VOLTAGE STATIC | 115 |
| WEIGHT STATIC | 29 LB |
| WIDTH | 11 IN |
