| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 12.7 IN |
| CATALOG NUMBER | C472V1 |
| CONNECTION DRAWING NO | 17050311.PCX |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 6.3-6.0/3.3-3.8 A |
| FRAME | M56 |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 16 IN |
| MANUFACTURE MODEL NUMBER | C472V1 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Cap |
| MOUNTING | Cushion Base |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 2 |
| OUTPUT | 1 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1,1725(2),208-230,56,ODP,CAP |
| PRODUCT SKU | CM-C472V1 |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725/1140(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.94 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.94 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725/1140 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 8 IN |
