| BEARING | Ball |
| BRAND | LEESON |
| C DIMENSION | 12.66 IN |
| CATALOG NUMBER | C340 |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | Totally Enclosed Fan Cooled |
| FRAME | 56C |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.5 |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 15.14 |
| MANUFACTURE MODEL NUMBER | C340 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | CAPACITOR START |
| MOUNTING | Round |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 3 HP |
| OVERLOAD | Manual |
| PRODUCT NAME | 1.5 1800 56N 115/230 TEFC CAP START |
| PRODUCT SKU | CM-C340 |
| ROTATION | Counterclockwise/Clockwise |
| RPM | 1800 |
| SERVICE FACTOR | 1.15 |
| SHAFT DIAMETER (IN IN.) | 0.630 IN |
| SHAFT EXTENSION | 1.88 |
| SPEED | 3450 |
| SUPPLIER | Regal Rexnord |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/230 V |
| WIDTH | 10.19 |
