| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 13.28 IN |
| CATALOG NUM | C317V1 |
| CATALOG NUM STATIC | C317V1 |
| CE | N |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Y |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | Totally Enclosed Fan Cooled |
| FRAME | M56Y |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 11 IN |
| HORSE POWER | 1-1/2 HP |
| HORSE POWER STATIC | 1-1/2 |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 17 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C317V1 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | CAPACITOR START |
| MOUNTING | Rigid Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Manual |
| POWER RATING IN KW | 1.1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Counterclockwise |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER IN IN | 0.875 IN |
| SHAFT EXTENSION | 1.44 |
| SKU | CM-C317V1 |
| SPEED | 1725 |
| SUPPLIER | Regal Rexnord |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674015754 |
| VOLTAGE | 230 V |
| VOLTAGE STATIC | 230 |
| WEIGHT STATIC | 32 LB |
| WIDTH | 11 IN |
